Description

Power rating (RMS)： 480W

Frequency response： 90 Hz-18 kHz (-6d B)

Nominal impedance：12Ω

SPL Continuous： 123 dB

Max SPL： 129 dB

Directivity：100 x 20 (H x V)

Transducers： 6 x 4"

Dimensions (mm)： H690 x W150 x D200

Weight： 9.5 kg

Panel material： 12mm birch plywood

Painted： Black environmentally friendly water-based paint

Features

The column sound system needs to solve the contradiction between volume power and bandwidth!

Design of Hzaudio's DL-6

Hzaudio's DL-6 is a 4-inch mid-diameter speaker unit design, which can better solve the problem of thin mid-low frequency that usually exists in small-diameter sound columns.

Through the investment of new technology, the speaker unit with 25mm voice coil can be used more efficiently, producing brighter and denser sound,which meets the needs of on-site applications.

The inherent clustering effect of the cone-shaped speaker unit makes the sound radiation angle gradually narrow as the frequency increases, resulting in narrowing of the high-frequency sound column radiation in the horizontal direction. The constant directivity cross structure design of the DL-6 makes the high-frequency sound column The horizontal radiation angle achieves 1 00-degree constant directivity control, effectively controlling the horizontal

DL-6 balances volume, power and high frequency extension very well!
