MA-205

Overall, the speaker design of the MA-205 combines advanced technology and careful detail processing to provide users with a high-quality audio experience.

Tel: 020-34882578

E-mail:sale@hzaudio.com

Description

MA-205

Break through space limitations and enjoy stunning sound effects，Dual 5-inch coaxial design, powerful performance, compact size

MA-\

MA-205 is a high energy density passive dual 5-inch 2-way system speaker that combines powerful sound performance with compact size design. Thanks to advanced technology and careful design, MA-205 can burst out shocking energy in a limited space, meeting your requirements for high-quality speakers.

Application scenarios

MA-205 is suitable for various audio application scenarios, including:

·Corporate events or exhibitions
·DJ listening
Small club sound reinforcement
Live performance stage monitoring or front fill
·Theater sublipal speakers

Excellent sound performance

The MA-205 has a wide coverage area of 100° x 100°, which can evenly deliver high-fidelity sound quality to the entire listening area. Whether you are indoors or outdoors, you can experience clear and detailed sound performance.

Compact design, flexible installation

The MA-205 is compact and lightweight, making it easy to install and transport, making it easy to use even in small spaces.

Flexible matching to achieve the best sound effect

MA-205 can be used with a specialized DSP processing program and CW-1A subwoofer to further improve sound performance and meet your professional audio needs in different scenarios.

MA-205, small size but big power, helps you create a wonderful audio feast!

design

Dual 5-inch coaxial design, high energy density

MA-205 adopts a dual 5-inch coaxial design. Both bass units are equipped with 45mm large-diameter voice coils and high-grade ferrite magnetic circuits, which can provide strong low-frequency response and excellent dynamic performance. The coaxial design enables high and low frequencies to radiate coaxially and at the same point, effectively reducing phase distortion caused by sound wave diffraction, thereby achieving more accurate sound restoration.

Polymer composite membrane tweeter, clear treble performance

The tweeter unit of MA-205 uses a 25mm voice coil polymer composite membrane, which has good high-frequency response and transient response, and can clearly restore the treble details in music, making the sound brighter and more thorough.

Precision phase-optimized crossover network smoothly connects high and low sounds

MA-205 adopts a precision phase-optimized crossover network to ensure precise phase connection between the high and low units and avoid sound quality degradation caused by phase distortion, thereby achieving smooth and natural sound transition and the best acoustic performance.

Sturdy box design, more resistant to collisions

The cabinet of the MA-205 is made of solid birch plywood, sprayed with a waterproof, wear-resistant and impact-resistant polyurea coating, and equipped with a solid perforated steel plate and an acoustic sound-transparent sponge on the back, which can effectively prevent dust and water droplets from splashing in Inside the speaker, extending the service life of the speaker.

Simple and convenient application

The bottom of the MA-205 speaker is designed with support holes to facilitate users to use support rods to support the speaker, meeting the needs of sound reinforcement applications in different scenarios.

Overall, the speaker design of the MA-205 combines advanced technology and careful detail processing to provide users with a high-quality audio experience.

Technical data

Speaker type

rated power

Frequency response

Nominal impedance

Sensitivity

Max SPL

Radiation angle

size

weight

Speaker unit

input interface
