speaker type：Dual 10-inch three-way line array speakers (Built-in precise phase crossover network)

rated power：900W RMS

bandwidth：50HZ-18kHz (-6db)

Nominal impedance：8Ω

Max SPL：145dB

Directivity：80 x 1-12

Size：313×860×465 (Ht×W×D)(mm)

weight：39.5 kg

Transducers：LF: 10" neodymium cone driver x 2 with 3" voice coil, MF: Horn-loaded 2.5" voice coil 8" neodymium driver x 1 HF: 3" voice coil pure titanium diaphragm

Input interface：neodymium magnetic compression driver x 2

Cabinet material：NL4MP*2

Surface treatment：15mm birch plywood black polyurea paint

Speaker type：Dual 8-inch line array system

Power rating：300W

Frequency response：75 Hz-19 kHz (-6dB)

Nominalimpedance：160

Max SPL：138 dB

Directivity：90 x 1-12

Dimensions：H255xW630xD375 (mm)

Weight：21 kg

Transducers：2 x 8" bass cone drivers,2.5" voice coil neodymium compression drivers

input interface：N L4M P*2

Panel material：birch plywood

Painted：Black polyurea coatings

Units：LF : 75mm Coil, 12" Passive Neodymium Unit X 2,MF : 75mm Coil, 10'Neodymium Unit X 1,HF : 75mm Coil, Pure Titanium Neodymium Unit X 2

Sensibility： /

Rated Power：LF : 800W RMS ; MF : 250W AES ; HF : 120W RMS;

Frequency Response：50 Hz-19 kHz

SPL Continuous：LF : 130 dB ; MF:131 dB ; HF:136 dB

SPL Max lW @ Im：LF : 136 dB ; MF:137 dB ; HF:142 dB

Dispersion：80xl0 ( H xV)

Dimensions：365x1166x580(LxWxH)(mm)

Weight：63 kg

Connector：8-Core[8 pole] Socket

Cabinet Material：15mm Birch Ply.A.ood

Painted：Black Polyurea

Units：LF: 10" neodymium cone driver x 2 with 3 " voice coil,MF: Horn -loaded 2.5 " voica coil 8" neodymium d river x l,HF: 2.5" voice coil pu re titanium diaphragm

Sensibility：/

Power rating(RMS)：800W RMS

.Frequency response：55 H2-18k Hz (-6dB)

SPL Continuous：/

Max SPL：143 dB

Directivity：80 x1-12

Dimensions：313x860x465(LxWxH)(mm)

Weight：39.5 kg

Connector：NL4MP*2

Panel material：15mm birch plywood

Painted： Black Polyurea
